Phase LED Driver  (CC)

Home Products Main/Line voltage_Constant Current Phase LED Driver  (CC)
LED Driver Search
Submit
Submit
Driver
Model
No.
Input
Voltage
(Vac)*
Output
Power
(W)
Output
Current
(mA)
Output
Voltage
(Vdc)
Case
Dimming
Download
MDR-602-250-10-R4
120-277
6
140
35-43
Plastic, Square, Side Feed
TRIAC / ELV dimmable on 120V
MDR-602-600-10-T6
120
8
600
10-14
Plastic, Square, Side Feed
ELV/TRIAC Dimmable
MDR-602-700-10-T6
120-277
9
700
10-13
Plastic, Square, Side Feed
ELV/TRIAC Dimmable
MDR-602-250-10-T6
120
10
250
40
Plastic, Square, Side Feed
ELV/TRIAC Dimmable
EDR-602-250-10-T5
120
11
250
30-45
Plastic, Rectangle, Side feed
ELV/TRIAC
MDR-602-350-15-R4
120-277
12
270
35-43
Plastic, Square, Side Feed
TRIAC / ELV dimmable on 120V
MDR-602-350-13-R1
120-277
13
200/350
30-38
Plastic, Square, Side Feed
TRIAC / ELV dimmable on 120V
MDR-602-1000-15-R4
120-277
13
1000
10-13
Plastic, Square, Side Feed
TRIAC / ELV dimmable on 120V
MDR-604-700-15-T5
220-240
14
700
13-20
Plastic, Rectangle, Side Feed
TRIAC/ELV Dimming
EDR-602-350-10-T5
120
14
350
37
Plastic, Rectangle, Side feed
ELV/TRIAC
EDR-602-400-14-T5
120
14
375
29-38
Round, Plastic, Bottom feed
ELV/TRIAC
MDR-602-350-15-R1
120
15
350
30-43
Plastic, Square, Side Feed
TRIAC/ELV Dimming
GA-9409-500-20-E-3-YY
120-277
20
350/400/450/500
30-40
Plastic, Rectangle
TRIAC / ELV dimmable on 120V
GA-9409-900-25-E-3-YY
120-277
22
500/700/900
10-25
Plastic, Rectangle
TRIAC / ELV dimmable on 120V
MDR-604-700-30-TA
220-240
28
700
30-40
Plastic, Rectangle, Side Feed
TRIAC/ELV Dimming
GA-9409-900-35-E-3-YY
120-277
34
500/700/900
30-38
Plastic, Rectangle
TRIAC / ELV dimmable on 120V
GA-9409-1050-40-E-3-YY
120-277
42
250/350/400/500/550/600/650/750/800/900/950/1050
30-40
Plastic, Rectangle
TRIAC / ELV dimmable on 120V
